AI Open Source RV1126 Development Board

Thinkcore is a leading China AI Open Source RV1126 Development Board manufacturers. Along with the SBC, we provides development materials including user manual, PDF schematic diagram, external expansion interface driver, BSP source code package, development tools, etc., which provides a perfect software and hardware development environment for application development. Starting from the SBC to realize the specific application requirements can not only reduce the product development cycle, realize the rapid launch of products, but also provide better scalability and flexibility for more project products by replacing the computing module.

Product features

1.TC-RV1126 develop board consists of RV1126 Gold Finger SOM andcarrier board.

2.TC-RV1126systemon module takes Low-consumption AIvisionprocessor Rockchip RV1126, with 14nm lithography process andquad-core 32-bit ARM Cortex-A7 architecture，integrates NEON andFPU— the frequency is up to 1.5GHz.

3.Built-in neural network processor NPU with computing power up to2.0 Tops realizes that the power consumption of AI computing isless than 10% of the power required by the GPU. With tools andsupporting AI algorithms provided,it supports direct conversionand deployment of Tensorflow,PyTorch，Caffe，MxNet，DarkNet,ONNX,etc.

4.The soM is only 67.6*58.7 mm，ups to 204PIN. Includes I2C，SPI,UART，ADC，PWM,GPIO，USB2.0，SDIO，I2S，MIPI-DSI,MIPI-CSI，CIF,PHYand other interfaces are equipped,meeting needs of moreusage scenarios.

5.TC-RV1126 carrier board,its size is only108*124 mm,includesmany interfaces an functions,such as Ethernet , OTG and USB2.0port，Audio input and output，MIPI display port，TF card slot,MIPI camera port,，DVP camera port，TTL，Power output，and so on.

Product application

TC-RV1126 Linux Intelligent develop board is widely used in face recognition, gesture recognition, gate access control, smart security, smart IP camera, smart doorbell/peephole, self-service terminals, smart finance, smart construction, smart travel and other industries.
